ATOMIC Pi, Intel Atom X5 Raspberry Pi Alternative

By on December 27, 2018
Pin It

If you are searching for a more powerful Raspberry Pi alternative, maybe this new ATOMIC Pi by Team IoT might be just the thing. The mini PC powered by a Intel Atom x5-Z8350 quad core processor with 2M Cache has launched via Kickstarter and is now available to back with early bird pledges from $34.

The board will come pre-loaded with Linux, but Windows 10 64-bit is also supported. The datasheet and a quick start guide will be available on AtomicPi.org.

ATOMIC Pi specifications:

  • SoC – Intel Atom x5-Z8350 quad core processor @ up to 1.92GHz with Intel HD graphics
  • System Memory – 2GB DDR3L-1600
  • Storage – 16GB eMMC flash, slot for SD expansion up to 256GB
  • Video Output – HDMI port
  • Connectivity
    • Gigabit Ethernet via Realtek RTL8111G transceiver
    • Dual band 802.11b/g/n/ac WiFi 5 via RT5572 with IPX connectors on board
    • Bluetooth 4.0 via CSR8510
  • USB – USB 3.0 and USB 2.0 ports
  • Sensor – 9-axis inertial navigation sensor with compass (BNO055)
  • Expansion – JST style connectors and a 26-pin header for power & GPIO
  • Debugging – TTL serial debug and expansion serial ports up to 3.6Mbps
  • Misc – Real time clock & battery
  • Power Supply – 5V/4A recommended. 4-15 watts typ. power consumption
  • Dimensions – 130 x 100 x 50 mm

A breakout shield which adds screw terminals, a 12V header, and a prototyping area is also available for purchase.

Atomic Pi board appears to be ready, as shipping is scheduled for the end of January 2019.
